產品簡介

Transko無源晶體,CS32H-F5020HM-16-48.000M-TR,CS32H,3225mm,48MHZ，尺寸3.2x2.5mm，頻率48MHZ，特蘭斯科小封裝晶體，3225mm高質量晶振，水晶振動子，貼片石英晶振，無源石英晶體，無源晶振，SMD晶體，石英晶體諧振器，輕薄型晶體，低成本晶振，低功耗晶振，低老化晶振，低損耗晶振，高品質晶振，高精度晶振，視聽設備晶振，便攜式設備晶振，娛樂設備晶振，可視化電話晶振，數字視頻晶振，筆記本電腦晶振，具有低成本高品質高精度的特點。石英晶振產品特別常用于視聽設備，便攜式設備，娛樂設備，可視化電話，數字視頻，筆記本電腦等應用領域。Transko無源晶體,CS32H-F5020HM-16-48.000M-TR,CS32H,3225mm,48MHZ.

產品詳情

Transko無源晶體,CS32H-F5020HM-16-48.000M-TR,CS32H,3225mm,48MHZ 參數表

■ SPECIFICATION

FREQUENCY RANGE

48.000MHz

FREQUENCY TOLERANCE @ 25ºC

STD: ±30ppm (See P/N guide for other options)

FREQUENCY STABILITY

STD: ±50ppm (See P/N guide for other options)

OPERATING TEMPERATURE RANGE

STD: 0°C ~ 70°C (See P/N guide for other options)

STORAGE TEMPERATURE RANGE

-55°C ~ 125°C

LOAD CAPACITANCE

STD: 18pF (See P/N guide for other options)

SHUNT CAPACITANCE

5.0pF max.

INSULATION RESISTANCE

500MΩ min. @ 100VDC± 15VDC

DRIVE LEVEL

300µW max.

AGING @ 25°C ± 3°C

±3.0ppm / 1styear max.

EQUIVALENT SERIES RESISTANCE

Fundamental:20.000MHz ~70.000MHz: 40Ω max.
3rdOvertone:60.000MHz ~ 115.000MHz: 100Ω max.
3rdOvertone:116.000MHz ~ 170.000MHz: 80Ω max.
5thOvertone:170.000MHz ~ 300.000MHz: 120Ω max.

OPERATION MODE

Fundamental,3rdOvertone,5thOvertone
